General

Supported disc types

DVD/CD-DA,CD,CD-R/CDRW,DVD+R/RW

Supported Video Formats

MPEG-1,MPEG-2,MPEG-4,JPEG

TV System

PAL/SECAM

Power requlrements

AC100-240 V,50/60Hz

Power Consumption

35W

Weight

4.0KG

Dimensions

W420 x H55 x D330 mm

Operating Temperature

5℃-35℃

Operating humidity

10%-75% (no condensation)

Recording

Recording format

DVD VIDEO

Recordable media

DVD+R/RW,DVD-R/RW,HDD(80GB)

Timer

Programs

8 Programa

Clock

Quartz lock (24-hour digital display)

Power off memory

Approx.1 hour 30 min.

Euro AV connectors

(21-pin connector)

AV connector input/output x 1

AV connector output x  1

This connector provides the video and audio signals for connection to a compatible color TV or monitor.

S-Video output

Y (luminance)-Ouutput level

1.0 Vp~p(75Ω)

C (color)-Output level

0.286 Vp~p(75Ω)

Jacks

S-VIDEO jack

Video Output

Output level

1.0 Vp~p(75Ω)

Jacks

RCA jack

Component video output(Y,Cb/Pb,Cr/Pr)

Y: 1.0 Vp~p(75Ω)

Output level

Cb/Pb,Cr/Pr: 0.7 Vp~p(75Ω)

Audio output

Output level

2 Vrms (1kHz,0db)

Numbers of channels

5.1Channels

Jacks

RCA jack

Audio characteristics

Frequency reponse

4 Hz to 44 kHz(DVD fs:96 kHz)

S/N ratio

100 db

Dynamic range

95 db

Total harmonic distortion

0.03%

Digital output

Optical digital output

Optical digital jack

Coaxial digital output

RCA jack

DV Input

IEEE 1394 standard

4 pin

Accessories

Audio/Video cable

1

RF Cable

1

Scart Cable

1

Remote control unit

1

“AA” size batteries

2

Operating instructions

1
