Specifications

1) Display mode: TFT active matrix system (16:9 / 4:3) - new panel

2) Screen size: 7"

3) Active area: 156 x 88.5mm

4) Resolution: 1,440H x 234V

5) Number of pixels: 337,000

6) Backlight: cold cathode filament tube

7) color configuration: RGB delta

8) Luminance: 300 - 350cd/m²

9) Video input signal: 1.0Vpp / 75Ω (composite video signal)

10) Audio input signal: 1Vpp / 10 KΩ

11) Audio output signal: 0.5W / 16Ω

13) Monitor: DC12V±10% / 1,000mA max. (use PS1210R, not incl.)

14) Remote control: 1 x 1.5V, CR2025 battery (incl.)

15) Power consumption: 8.5W

16) Built-in speaker: 0.5W / 16Ω

17) Operating temperature: 0°C to 60°C

18) Storage temperature: -25°C to 80°C

19) Dimensions: 171 x 125 x 19mm

20) Weight: 400g
