Detailed Product Description
-- Motion/Voice detection mode available -- Alarming while strange situation was detected by camera -- Night Vision (Effective range: 5m) -- 2.5 inches LCD with 480 X 234 resolutions in palm receiver -- Built-in Microphone in camera and speaker in receiver for audio monitoring -- 3 channels available to avoid possible interference -- Up to 100m (330ft.) transmission range in open space
------Camera: Imaging Sensor : CMOS CMOS Total Pixels : 628x582(PAL) ; 510x492(NTSC) Horizontal Resolution: 380 TV Lines View Angle: 60 Degree Minimum Illumination: 0 Lux Transmission Frequency: ISM 2,400~2,483 MHz Transmission Power : 10mW/CE; 2mW/FCC Modulation Type: FM Bandwidth : 18 MHz Power Supply: +9 VDC Motion Detection Angle: Horizontal: 60 degree; Vertical: 15 degree Sound Control Sensitivity: >75 dB Consumption Current : 120mA & 220mA(IR ON) Unobstructed Effective Range : 100m (Min) Night Vision Range: 5m Dimensions(WxDxH): 60 x133 x86 mm Weight : 195 g Operating Temperature : -10 ~ +50 (Degree C) / +14 ~ +122 (Degree F) Storage Temperature: -20 ~ +85 (Degree C) / -4 ~ +185 (Degree F) Operating Humidity: 85% RH
--------Receiver: LCD Size : 2.5 inch TFT LCD Resolution: 480 x 234 Receiving Frequency: ISM 2,400MHz~2,483MHz Intermediate Frequency: 480MHz Demodulation Type: FM Receiving Sensitivity: <= -85dBm Power Supply: +9 VDC Consumption Current : 400mA Dimensions(WxDxH): 68 x 149 x 26 mm (Excluding Antenna) Weight : 170 g Operating Temperature : 0 ~ +50 (Degree C) / +32 ~ +122 (Degree F) Storage Temperature: -20 ~ +80 (Degree C) / -4 ~ +176 (Degree F) Operating Humidity: 85% RH
|
