Product Detailed Description
-- 1/3 inch color CCD solutions; 420 TV Lines hi-quality picture display
-- High strength and water-resistant cables, Max 30m detecting depth underwater
-- Max. 360 degree horizontal rotating angles
-- Against erosion, vibration, bump and water
-- Work under most of harsh environment
-- Infra-Red lights provide Night-vision
Detector Profomance:
|
Item |
Specification or Parameter |
Remarks |
|
Image Performance |
|
|
|
Image Sensor |
1/3-inch CCD |
|
|
Effective Pixels |
500´582 pixels (PAL)
510´ 492 pixels (NTSC) |
|
|
VF System |
NTSC/PAL |
Option |
|
Lens Specification |
6mm fixed lens F1. 6 Cs Mount |
|
|
Visual Angle |
42 Degree |
|
|
Lowest Illuminance |
0 l u x |
|
|
Video Output |
0.8~1.2V pp / 75 ohm |
|
|
Motor Performance |
|
|
|
Horizontal Turn Angle |
360 degrees |
|
|
Integrated Equipment |
|
|
|
Underwater Night Visual Distance |
1m to 3m |
Depending on water turbidity |
|
Maximum waterproof Depth |
30m |
|
|
Power Supply Voltage |
DC 12V |
|
|
Current Consumption of Integrated Equipment |
350+/-30mA |
When all circuits are on |
|
Current Consumption in Standby Mode |
< 20mA |
|
|
Working Temperature |
-10~+55¡æ |
|
|
Dimensions |
F100´H154 mm |
|
|
Weight |
1.5 kg |
Including 30m cable |
|
Anti-dust/Waterproof Class |
IP68 |
|
LCD Performance
|
Item |
Specification or Parameter |
Remarks |
|
LCD Screen Type |
7¡±TFT color LCD display |
|
|
Effective Pixels |
480(H) ´ 3(R, G, B) ´ 234(V) |
|
|
Effective Area of LCD |
154.08 mm (width) ´ 86.58 mm (height) |
|
|
VF System |
NTSC/PAL |
Automatically identify |
|
Dot Matrix Dimension |
0.107mm (W) ´ 0.370mm (H) |
|
|
Visual Angle |
65¡ã |
|
|
Response Time |
Rise 10ms/Fall 30ms |
|
|
Contrast |
300~400 |
|
|
Brightness |
300-400cd/m2 (adjustable) |
|
|
Color Composition |
Combining R, G, B. |
|
|
Video Input Impedance |
75¦¸ |
|
|
Video Input Level |
1.0~1.2Vpp |
|
|
Power Supply Voltage |
9V ~12V/1.5A |
|
|
Current Consumption of Integrated Equipment |
450mA |
|
|
Working Temperature |
-10~+45¡æ |
|
|
Related Humidity |
85%RH |
|
|
Dimensions |
197mm (L) ´126mm (W) ´ 28mm (H) |
|
|
Weight |
0.64 kg |
|
Battery Performance
|
Item |
Specification or Parameter |
Remarks |
|
Battery Type |
Lead-acid battery |
|
|
Battery Capacity |
4.5 AH |
|
|
Battery Internal Resistance |
40 m¦¸ |
|
|
Chargeable Voltage |
13.5~13.8V |
|
|
Times of Recharging |
250~300 times |
|
|
Dimensions |
90mm (L) ´70mm (W) ´ 101mm (H) |
|
|
Weight |
1.45 kg |
|
|
Stand-by Time |
10~25 days |
|
