USB-C Docking Station with Dual HDMI
| Model No. | CWG65296 |
|---|---|
| Sample Time | 7 days |
| OEM / ODM | Available |
| Port | Shenzhen or HK,China |
| Views | 0 views |
US$ 2~4 /Piece | Get Latest Price
Product Detailed Description
A small flat dock in textured black plastic, close to square in plan and slim enough to slip into a laptop sleeve. A short captive USB-C lead leaves one edge and plugs into the host, while the opposite edge carries the video and data sockets. Twin HDMI outputs sit beside a pair of USB-A ports and a USB-C data port, with a separate USB-C charging input feeding the dock. It is the shape a hybrid worker drops on a hot-desk between meetings, connecting a borrowed monitor and keyboard.
- Flat square shell in textured black plastic sits flush on a desk without tipping when cables pull
- Twin HDMI sockets on the rear edge let a user run two monitors from a single laptop cable
- Captive USB-C lead plugs straight into the host, so there is no separate cable to lose or mislay
- Separate USB-C charging input feeds the dock while the host draws power through the same lead
- USB-A and USB-C data ports along the front take a keyboard, mouse and flash drive at once
| Upstream Usb-c | up to 81W host charging (100W PD in, ~19W dock consumption) |
| Downstream Usb-a | 5V/0.9A; Downstream USB-C data port: 5V/1A |
| Category | Details |
| Video Output | 2 × HDMI up to 3840×2160 @ 60Hz (DP 1.4 MST), HDCP 1.4/2.2 supported |
| Cable | USB 3.1 Type-C cable, OD 4.2mm, length 15cm |
| Dimensions & Material | 60.16 × 60.16 × 12.85 mm, ABS textured plastic / Black |
